CM241 AC Clamp Meter
- 5999-count high-resolution display
- True RMS measurement for accurate readings
- AC current measurement up to 600A
- Multi-function: Voltage, Resistance, Capacitance, Frequency & Temperature
- NCV (Non-Contact Voltage) detection
- Data Hold & Max/Min recording
- Backlit LCD for low-light environments
- Compact design with 27mm jaw opening
HIKOTEK CM241 AC Clamp Meter is a compact 5999-count True RMS clamp meter designed for safe and convenient electrical measurement. It is suitable for measuring AC current, AC/DC voltage, resistance, capacitance, frequency, temperature, diode, and continuity, with NCV detection for quick non-contact voltage checking.
SPECIFICATIONS
- Display: 5999 counts
- DC Voltage: 1 mV–1000 V ±(0.5%+3)
- AC Voltage: 1 mV–750 V ±(1.2%+10)
- AC Current: 0.01 A–600 A ±(3.0%+10)
- Resistance: 0.1 Ω–40 MΩ ±(1.2%+8)
- Capacitance: 1 nF–30000 µF ±(5.0%+10)
- Frequency: 10 Hz–10 MHz ±(0.1%+3)
- Temperature: -20 °C–1000 °C ±(1 °C)
- NCV Detection: Yes
- True RMS: Yes
- Data Hold: Yes
- Max/Min: Yes
- Backlight Display: Yes
- Diode & Continuity Test: Yes
- Auto Power Off: Yes (approx. 15 minutes)
- Measurement Method: Double Integral A/D Conversion
- Sampling Rate: 3 times/sec
- Jaw Opening: 27mm
- Power Supply: 2 × 1.5V AAA batteries
- Product Size: 176 × 68 × 33 mm
- Weight: Approx. 300g
